EC TDS Salinity Meter รุ่น HI2030 เป็นเครื่องวัดไฮบริด วัตกรรมใหม่ล่าสุดจาก Hanna Instrument ซึ่งนำเสนอเทคโนโลยีที่ทันสมัยที่สุด สำหรับการวัด EC/TDS/Salinity
มีย่านการวัด EC 0.00 ถึง 500.0 mS/cm มีย่านการวัด TDS 0.00 ถึง 400.0 g/L และย่านการวัดความเค็ม Salinity มีย่านการวัด 0.0 to 400.0 % NaCl; 2.00 to 42.00 PSU; 0.0 to 80.0 g/L
การออกแบบที่ชาญฉลาดและบางเฉียบทำให้ใช้เป็นแบบยึดติดบนผนังหรือหยิบถือได้สะดวก คุณภาพสูงมีใบรับรองการสอบเทียบ (Certificate) จากโรงงาน มีคู่มือการใช้งานภาษาไทย ขายราคาถูก จัดส่งทั่วไทย
วิดีโอเเนะนำการใช้งาน HI2030
Digital Electrodes
Edge electrodes are highly advanced, featuring a built-in microchip that stores calibration information
Four Ring Probe
Four ring platinum probe that has a built in temperature sensor for ATC measurements.
Wall Mount
Using wall mount cradle, So can be placed on a wall, leaving zero footprint on the benchtop space
Data Logging
edge allows you to store up to 1000 log records of data. Data can be logged on demand (200 records)
Specification
| SKU | HI2030-02 |
|---|---|
| Product Name | edge® Multiparameter EC/TDS/Salinity Meter |
| pH Range | -2.00 to 16.00 pH, -2.000 to 16.000 pH* |
| pH Resolution | 0.01 pH, 0.001 pH* |
| pH Accuracy | ±0.01pH, ±0.002 pH* |
| pH Calibration | Automatic, up to 3 points (5 points*) calibration, 5 standard (7 standard*) buffers available (1.68*, 4.01 or 3.00, 6.86, 7.01, 9.18, 10.01, 12.45*) and 2 custom buffers* |
| pH Temperature Compensation | Automatic -5 to 100º C (23 to 212º F) (using integral temperature sensor) |
| EC Range | 0.00 to 29.99 μS/cm, 3.00 to 29.99 μS/cm, 30.0 to 299.9 μS/cm, 300 to 2999 μS/cm, 3.00 to 29.99 mS/cm, 30.0 to 200.0 mS/cm, up to 500.0 mS/cm, absolute conductivity ‡ |
| EC Resolution | 0.01 μS/cm, 00.1 μS/cm, 0.01 μS/cm, 0.01 mS/cm, 00.1 mS/cm |
| EC Accuracy | ±1% of reading (±0.05 μS/cm or 1 digit, whichever is greater) |
| EC Calibration | 1 Cell Factor calibration; 6 standards available |
| TDS Range | 0.00 to 14.99 ppm (mg/L), 15.0 to 149.9 ppm (mg/L), 150. to 1499. ppm (mg/L), 1.50 to 14.99 g/L, 15.0 to 100.0 g/L, up to 400.0 g/L absolute TDS ‡ (with 0.80 factor) |
| TDS Resolution | 0.01 ppm, 0.1 ppm, 1 ppm, 0.01 g/L, 0.1 g/L |
| TDS Accuracy | ±1% of reading (±0.03 ppm or 1 digit, whichever is greater) |
| TDS Calibration | through EC calibration |
| EC/TDS Temperature Compensation | Automatic -5 to 100 ºC (23 to 212 ºF); NoTC - can be selected to measure absolute conductivity. |
| Temperature Correction Coefficient | 0.00 to 6.00% / ºC (for EC and TDS only). Default value is 1.90% / ºC |
| EC to TDS Conversion Factor | 0.40 to 0.80 (default value is 0.50) |
| Salinity (% NaCl) Range | 0.0 to 400.0% NaCl * |
| Salinity (% NaCl) Resolution | 0.1% NaCl |
| Salinity (% NaCl) Accuracy | ±1% of reading |
| Salinity (% NaCl) Calibration | Single point with HI 7037L Standard |
| Salinity (PSU) Range | 2.00 to 42.00 PSU * |
| Salinity (PSU) Resolution | 0.01 PSU, |
| Salinity (PSU) Accuracy | ±1% of reading |
| Salinity Range | 0.0 to 80.0 g/L * |
| Salinity Resolution (ppt) | 0.01 g/L |
| Salinity Accuracy (ppt) | ±1% of reading |
| Dissolved Oxygen Measurement Type | polarographic |
| Dissolved Oxygen Range | 0.00 to 45.00 ppm (mg/L), 0.0 to 300.0% |
| Dissolved Oxygen Resolution | 0.01 ppm (mg/L), 0.1% |
| Dissolved Oxygen Accuracy | ±1.5% of reading |
| Dissolved Oxygen Calibration | One or two points at 0% (HI 7040) and 100% (water saturated air) |
| Dissolved Oxygen Temperature Compensation | 0.0 to 50.0 ºC (32.0 to 122 ºF) |
| Salinity Compensation | 0 to 40 g/L 1 g/L |
| Altitude Compensation | -500 to 4,000 m (-1640 to 13120’) 100 m (328’) |
| Temperature Range | -20.0 to 120.0 ºC, -4.0 to 248.0 °F |
| Temperature Resolution | 0.1 °C, 0.1 °F |
| Temperature Accuracy | ±0.5 °C, ±1.0 °F |
| EC/TDS Probe | HI 763100 EC/temperature probe |
| Logging Type | Manual Log on Demand (Max. 200 logs); Manual Log on Stability (Max. 200 logs); Interval Logging 100 lots, Max. 600 logs/lot |
| Logging Memory | Up to 1000 records |
| Connectivity | 1 micro USB port for charging and PC connectivity, 1 USB port for storage |
| GLP | yes |
| Battery Type/Life | Built-in rechargeable battery with up to 8 hours of continuous use |
| Power Supply | 5 VDC adapter (included) |
| Environment | 0 to 50°C (32 to 122°F), RH max 95% non-condensing |
| Dimensions | 202 x 140 x 12.7mm (8” x 5.5” x 0.5”) |
| Weight | 250 g (8.82 oz) |
| Ordering Information | HI2030 EC kit includes |
| Notes | * temperature limits will be reduced to actual probe/sensor limits ** with temperature compensation function disabled *** for standard mode only (logging) |
